Enterprise-Grade, Scalable Storage Solutions for Large-Scale Deployments:
The PROMISE Vess A7000 Series is a scalable storage appliance designed for mid- to large-scale enterprise deployments across sectors such as banking, retail, manufacturing, and government. It offers robust data protection via PromiseRAID on the A7000 and extended capacity through the Vess R Series. Available in two high-capacity enclosures—3U 16-drive (A7600) and 4U 24-drive (A7800)—it balances performance and reliability when paired with an Intel E5 CPU. For very large needs, capacity can be extended cost-effectively using the Promise JBOD, avoiding an extra RAID server. The solution emphasizes scalability, ease of administration, and total cost of ownership.
- Robust data protection with PromiseRAID and scalable capacity via the Vess R Series
- Two high-capacity enclosure options: 3U 16-drive (A7600) and 4U 24-drive (A7800)
- Balanced performance and reliability when paired with an Intel E5 CPU
- Cost-effective scalability using Promise JBOD without requiring an extra RAID server
| Vess A6000P Series Specifications |
| |
Vess A7600 |
Vess A7800 |
| Form Factor |
3U, 19" Rackmount |
4U, 19" Rackmount |
| Number Of Drives |
16 Drives (3.5") |
24 Drives (3.5") |
| Drive Type |
12Gbs SAS/ 6Gbs SATA @ 3.5”, SSD capable @2.5”, Hot Swappable |
12Gbs SAS/ 6Gbs SATA @ 3.5”, SSD capable @2.5”, Hot Swappable |
| Internal Storage |
128GB |
128GB |
| System Processor |
Intel® Xeon® E5-2603v4, E5-2600v4 series optional based on demand |
Intel® Xeon® E5-2609v4, E5-2600v4 series optional based on demand |
| Storage Expansion |
Optional Vess SAS and iSCSI Storage |
Optional Vess SAS and iSCSI Storage |
| Max # of HDDs Supported |
Up to 96 drives through SAS JBOD expansion(iSCSI optional) |
Up to 104 drives through SAS JBOD expansion(iSCSI optional) |
| RAID Levels |
0, 1, 1E, 3, 5, 6, 10 (0+1), 30, 50, 60. Any combination can exist at the same time |
| Power Supply |
Redundant 550W for each power, Hot swappable N+1 Design (800W optional with A7800 only) |
| Dimensions |
131 x 503 x 447 mm (5.1 x 19.8 x 17.6 in) |
173 x 503 x 447 mm (6.8 x 19.8 x 17.6 in) |
| Weight |
System W/O HDD: 17.656 kg
System W/ HDD: 28.699 kg |
System W/O HDD: 22.484 kg
System W/ HDD: 39.048 kg |
| OS Supported (64-bit) |
Windows 10, WS 2016, WS 2019 |
| |
